50-0500 FH
Technical Specification
- Manual Adjustment of Backrest, Knee Rest, Height
- Trendelenburg/ Reverse Trendelenburg
- Detachable ABS Head and Foot Panel
- Easily Lockable Fold away ABS Side Rails
- Perforated Mild Steel Four Section Top
- Angle Indicator for Backrest Position and Trendelenburg
- Urine Bag Holder
- IV Pole Socket Located at Four Corners
- Protective Plastic Corner Buffer
- Twin Casters 125mm, Two with Lock
- All MS Parts are Pre-treated and Epoxy Powder Coated
Technical Data
- Overall Dimension Buffer to Buffer 2185mm x 1085mm (L x W)
- Platform Dimension 1900mm x 900mm (L x W)
- Minimum Height without Mattress 560mm
- Maximum Height without Mattress 790mm
- Safe Working Load 200 kg
Optional Accessories
- Four Section Mattress with 4″ thick PU foam of 40 Density
- Height Adjustable Stainless Steel IV Pole
- Oxygen Cylinder Holder for Small Cylinder
- X ray permeable Backrest with cassette Holder
