    -86°C Chest ULT Freezer-128L
    -86°C Chest ULT Freezer-128L
    -86°C Chest ULT Freezer-128L
    -86°C Chest ULT Freezer-128L
    -86°C Chest ULT Freezer-128L
    -86°C Chest ULT Freezer-128L
    -86°C Chest ULT Freezer-128L
    -86°C Chest ULT Freezer-128L
    -86°C Chest ULT Freezer-128L
    -86°C Chest ULT Freezer-128L
    -86°C Chest ULT Freezer-128L
    -86°C Chest ULT Freezer-128L
    arrow
    arrow
    Add To Cart Download

    NE-86W128

    Application:

    -86℃ ULT Freezer is specially designed for long term storage of various biological products,such as germs, virus, erythrocytes, leukocytes, cutis. It can be installed in institutions including blood banks, hospitals, epidemic prevention services, research institutes and laboratories for electronic and chemical plants, biological engineering institutes and marine fishery companies.



    Temperature Control:

    • Microprocessor control, Large LED display inner temperature clearly, and with easy viewing.
    • The inner temperature can be adjustable at the range of -40℃~-86℃, with an increment of 0.1℃.
    • Lock and password for protection to prevent arbitrary adjustment of operating parameters.
    • Optional 7 inch LCD touch screen display system.



    Safety Control:

    Malfunction Alarms: High temperature alarm, low temperature alarm, Sensor failure, Power failure alarm, low voltage of backup battery. Over temperature alarm system, set the alarm temperature as requirements.



    Three Alarming Methods: Buzzer alarming, digital flashing alarming and Remote alarm.



    Protection Function: Protection function: power-on delay, Shutdown intervals.



    Refrigeration System:

    • Optimized cascade refrigeration technology, SECOP compressors.
    • Specially designed Heat Exchanger, heat transfer high efficient, save Energy.
    • V.I.P insulation panels to ensure the insulation performance.
    • CFC-Free overall polyurethane foaming insulation.
    • High efficient hydrocarbon refrigerant.



    Ergonomic Design:

    • 7 inch LCD touch screen display, and data logger with USB port (optional).
    • Safety door lock, preventing unauthorized access.
    • Wide voltage design from 192V to 242V.
    • Double inner doors to reduce the loss of cold after opening the door.
    • Suitable for 2 inch and 3 inch international standard cryo boxes.
    • Pressure-balanced port design, easy to open the door.
    • Heavy type caster and locking adjustable screw, easy to move and fix.
    • Ultra-simple condenser filter design, convenient for maintenance and cleaning.

    Colour Touch Screen            Large Digital Screen Display





    Optional Accessories



    Technical Data

    ModelNE-86W128
    Technical DataCabinet TypeChest
    Climate ClassN
    Cooling TypeDirect cooling
    Defrost ModeManual
    RefrigerantHydrocarbon, Mixing
    PerformanceCooling performance (℃)-80
    Temperature Range (℃) -40~-86
    Power (W)480
    Energy consumption (KW.H/24H)4.5
    MaterialExterior MaterialGalvanized steel powder coating
    Interior MaterialStainess steel
    Insulation MaterialPUF+VIP
    DimensionsCapacity(L)128
    Interior Dimensions (W*D*H)630×440×470 (mm)
    Exterior Dimensions (W*D*H)850×660×1020 (mm)
    Package Dimensions (W*D*H)930×755×1150 (mm)
    Container load (20'/40')36/72
    Thickness of Cabinet Foamed Layer90mm
    Thickness of Door90mm
    Capacity for 2 inch boxes96
    Inner door——
    Power Supply(V/Hz)220V/50Hz
    Controller FunctionsDisplayLarge digital display & adjusting keys
    High/Low TemperatureY
    Hot CondenserY
    Power FailureY
    Sensor ErrorY
    Low BatteryY
    High Ambient TempY
    Alarm modeSound and light alarm, remote alarm terminal
    AccessoriesCasterY
    Test HoleY
    Shelves(stainless steel)——
    Chart Temperature RecorderOptional
    Door locking deviceY
    HandleY
    Pressure balance holeY
    Racks & BoxesOptional













          -86°C Chest ULT Freezer-128L
