    Clinical Use Anaesthesia Machine
    Clinical Use Anaesthesia Machine
    Clinical Use Anaesthesia Machine
    Clinical Use Anaesthesia Machine
    arrow
    arrow
    Add To Cart Download

    Model No.:

    Features:

    • Deep and spacious drawer units & convenient footrest
    • Wide monitoring shelf at eye level with securing a provision
    • Convenient swivel common gas outlet
    • Hook for the breathing circuit
    • Wipe-clean stainless steel table top
    • Auxiliary high-pressure Oxygen outlets.
    • An extended platform at rear for two 10 Ltr water capacity cylinders* (optional)
    • Open / Close circuit switch control
    • Pin indexed yokes for O2 & N2O
    • Convenient mounting of circle absorber
    • Choice of a back bar for SELECTATEC or Cagemount vaporizers
    • Active/passive anesthetic gas scavenging interface and suction (optional)
    • Integrated rear bumper/ side handle for improved maneuverability
    • Large, roller bearing, anti-static castors with front wheel brakes

    Safety Features:

    • Hypoxic guard as the standard feature with all machines
    • Emergency oxygen flush
    • Alarm to provide the audible indication of O2 supply pressure failure
    • Nitrous Oxides shut off in the event of O2 failure
    • Colour coded internal pipework
    • Pipelines with gas selective connectors for O2, N2O & Air

    Other Details:

    • Vaporiser Mounting Space: Dual
    • Selectatec Mounting: Optional
    • Circle Absorber: Optional
    • Bulk Cylinder Platform: Optional
    • Auxiliary Flowmeter: Optional
    • Stainless Steel Body: Optional
    • Electrical Distribution Panel: Optional
    • Venturi Suction: Optional
    • Air Entrainment Valve: Optional
    • Air/N O Interlock: Optional
    • MOX/MNO Conversion kit: Optional
    Technical Specifications
    Cylinder Yokes1 O2 + 1 N2O
    Hypoxic GuardYes
    Rotameter Tubes2 (1 O2 + 1 N2O)
    On and Off SwitchOptional
    Basal FlowOptional
    Pipeline InletYes (NIST)
    O Gauge2
    N O Gauge2



          Clinical Use Anaesthesia Machine
