NE-KYC-L1100G(F)
Application:
Auto Defrost, Forced-Air Circulation Suitable for hospitals, blood banks, epidemic prevention, animal husbandry areas, pharmaceutical companies and research institutes. Designed to store pharmaceuticals, medicine, vaccines, biological materials, testing reagents and laboratory materials.
Temperature Control:
- Microprocessor control, Large LED display inner temperature clearly, and with easy viewing.
- The inner temperature can be adjustable at the range of 2℃~15℃, with an increment of 0.1℃.
- Multiple sensors to display or control the temperature.
- Lock and password for protection to prevent arbitrary adjustment of operating parameters.
Safety Control:
Malfunction Alarms: High temperature alarm, low temperature alarm, Sensor failure, Power failure alarm, low voltage of backup battery, Over temperature alarm system, set the alarm temperature as requirements.
Three Alarming Methods: Buzzer alarming, digital flashing alarming and Remote alarm.
Protection Function: Power-on delay, time between stops. Chart temperature recorder (Optional).
Refrigeration System:
- Highly efficient famous brand compressor and fan, with a high efficient refrigeration effect.
- 70mm thick foam insulation, better insulation effect, help to maintain temperature stability inside the freezer.
- Forced-Air Circulation for large airflow with special air ducts to guarantee inner temperature consistency.
- Large area of the evaporator design, strong cooling and high temperature uniformity.
- HCFC refrigerant.
Ergonomic Design:
- Safety door lock, preventing unauthorized access.
- Wide voltage design from 192V to 242V.
- Adjustable shelves design.
- Heavy duty casters with break.
Technical Data
| Model | NE-KYC-L1100G(F) | |
| Technical Data | Cabinet Type | Vertical |
| Climate Class | ST | |
| Cooling Type | Forced air cooling | |
| Defrost Mode | Auto | |
| Refrigerant | HC,R290 | |
| Performance | Cooling performance(℃) | 4 |
| Temperature Range(℃) | 2～8 | |
| Control | Controller | Microprocessor (Dixell) |
| Display | LED | |
| Alarm | Audible, Remote | |
| Material | Interior | Galvanized steel powder coating（white）stainless steel is optional |
| Exterior | Galvanized steel powder coating（white) | |
| Electrical Data | Power Supply(V/Hz) | 220/50 (115/60 is optional) |
| Power(W) | 360 | |
| Dimensions | Capacity(L) | 1100 |
| Net/Gross Weight(approx) | 165/195 (kg) | |
| Interior Dimensions(W*D*H) | 1160×680×1380 (mm) | |
| Exterior Dimensions(W*D*H) | 1300×822×1880 (mm) | |
| Packing Dimensions(W*D*H) | 1400×950×2020 (mm) | |
| Functions | High/Low Temperature | Yes |
| Remote Alarm | Yes | |
| Sensor Failure | Yes | |
| Door Ajar | Yes | |
| Lockage | Yes | |
| Inner LED light | Yes | |
| Accessories | Caster | Yes |
| Test Hole | Yes | |
| Shelves/Inner Doors | 5/- | |
| Foaming Door | optional | |
| Temperature Recorder | optional | |
