78-8604
| Approximate Technical Data | |
|---|---|
| Main Input | 220~240VAC, 50/60Hz |
| Rotor | 8 x 15ml and 6 x 50ml Angle head Rotor. |
| Speed / R.C.F | 5000 RPM/3100 X G |
| Temperature | -10°C to 25°C |
| Vessel/Chamber | Stainless Steel |
| Memory | 8 Programs Storage Memory. |
| Speed Regulator | Programable Preset RPM With3% Accuracy. |
| Timer | Programmable Predefine Time Range 1 To 99 Minutes. |
| Display | TFT Colour Display With Actual RPM And Actual RCF. |
| Motor | Brush Less Ac Induction Motor With Thermally Protected. |
| Drive | Ac Drive With High And Low Voltage Protection. |
| Gas Hinge | Door will open Automatically And Prevent Door Falling |
| Compressor | Heavy Duty with R134a Gas |
| Controller | It Is Microprocessor Controlled And Programmable For Pre Set RPM / RCF And Predefined Time |
| Lid Lock | A. The Centrifuge Will Not Run If Lid Will not Locked B. The Lid Will Lock Immediately When Door Is Closed C. The Lid Remain Locked Till Rotor Become Standstill D. If Power Failure Lid Can Be Open By Alternate Mechanism |
| Imbalance | If Rotor Is Imbalance, Machine Will Stop With Message on Display |
| Acceleration | Adjustable Minimum '4' and Maximum Up To '12’ |
| Deceleration | Adjustable Minimum '4' and Maximum Up To '12’ |
