Table Top Steam Sterilizer
Introduction :
Table top autoclave is fully automatic, it takes steam as its sterilization medium which is fast, safe and economic. They are commonly used in medical health care institution or R&D institution to make the sterilization for wrapped or unwrapped instrument, fabric, utensils, culture medium, unsealed liquid, etc.
Construction :
- The sterilizer consists of a sterilizer body, a sealing door, a pipe system, and a control system. The door opening direction is upward, and the inner chamber material is made of SS 304 stainless steel plate.
Features :
Operation interface :
The LCD touch screen can display temperature, pressure, time, operating status, error and alarm information, etc .There are different color changes in each stage of sterilization. It is convenient for users to observe the sterilizer running status. More importantly, the fault alarm not only displays the fault code, but also automatically displays the reason analysis and solution.
Multiple Safety Protection Devices :
Automatic over-temperature protection device, multiple control and protection of evaporator, door safety interlock protection, double over-pressure protection device, etc.
Mobile Temperature Sensor :
The mobile temperature probe can directly detect the internal temperature of the liquid to ensure the sterilization effect of the liquid.
Automatic Door Structure :
Sterilizer adopts automatic door structure, which is fast and convenient to operate, effectively protects human body and prevents scalding.
Vacuuming System :
High efficiency vacuum extraction system, low working noise, over 90KPa extreme vacuum, fast extraction speed, good dryness, more complete sterilization.
A Variety of Programs :
There are exposed procedures, packaging procedures, rubber procedures, dressing procedures, liquid procedures, liquid customization, solid customization, medium sterilization procedures, B&D testing, vacuum testing and media dissolution procedures.
Operating Temperature, Pressure & Voltage :
- Sterilizing Temp.: 121°C & 134°C.
- Sterilizing Pressure: 1.2 to 2.2 kg/ cm (15 PSI to 30 PSI)
- Power supply 220±10% V, 50Hz.
Other Features :
- Heating, sterilizing, exhausting and drying is completely automatic.
- Chamber is heated by film heater, saving energy and time.
- 0.22μm high efficiency air filter to avoid re-contamination of sterilized materials with filtration efficiency over 99.5%.
- Water filter in tank and chamber are quick to disassemble and easy for cleaning.
- Built-in stainless steel water tank.
- Standard built-in printer.
- Standard USB port.”
| Dia (mm) | Depth (mm) | Capacity (Ltr.) | Elect. Load (kw) | Voltage | Frequency | Model No. |
|---|---|---|---|---|---|---|
| 250 | 550 | 25 | 3.8 | 230V | 50Hz | 58-1201 |
| 316 | 621 | 45 | 5.8 | 230V | 50Hz | 58-1203 |
| 386 | 520 | 60 | 6.2 | 230V | 50Hz | 58-1205 |
| 386 | 692 | 80 | 6.2 | 230V | 50Hz | 58-1207 |
