    Vertical Autoclave Fully Automatic

    Introduction :
    Vertical Autoclave Fully Automatic triple wall model comprises of steam jacket electrically heated, inner chamber & lid made of stainless steel 316, works on 3-phase, 440V, 50HZ supply fitted with automatic pressure control switch, safety valve, pressure gauge, compound gauge, etc.



    Construction :
    Chamber :

    The Jacket & outer body made of heavy gauge, stainless steel 304, Fitted with stainless steel forged ring and forged lid, chamber & jacket are Fitted with two safety valve of stainless steel, pressure gauge, water outlet and inlet ball valve and vacuum
    breaker, Air inlet valve, stainless steel steam condenser, tube with stainless steel eject valve.

    Steam Generator :
    The steam generator is made out of stainless steel heavy gauge fitted with pressure gauge and water draining valve.
    Outer Cover :
    The outer cover is made out of stainless steel, duly insulated with high density mineral wool from the inner chamber and fitted with outer.

    • Operating Temperature, Pressure & Voltage :
    • Sterilizing Temp.: 121°C & 134°C.
    • Sterilizing Pressure: 1.2 to 2.2 kg/ cm (15 PSI to 30 PSI)
    • Power supply 440v, 3 Ph, 50Hz.

    Other Features :

    • Three sensor, one sensor is main controlling drain line and two sensor are scanning of different types of chamber area.
    • Digital Temperature controller.
    • Top loading radial locking door.
    • Automatic low water level cut off systems.
    • High & low temperature alarm.
    • Built in thermal printer facility.
    • Fully automatic HMI / PLC controller.



    Dia
    (mm)
    Depth
    (mm)
    Capacity
    (Ltr.)
    Elect. Load
    (kw)
    VoltageModel No.
    300500483440V58-1353
    350500503440V58-1355
    400600786440V58-1357
    450600986440V58-1359
    5007001376440V58-1361
    5507501789440V58-1363
