Introduction :
Vertical cylindrical Autoclave comprises of steam jacket electrically heated, inner chamber & lid made of S.S. Fitted with automatic pressure control switch, safety valve, pressure gauge, compound gauge, temperature gauge, etc.
Chamber :
- The chamber is made of heavy gauge, S.S. 316/304, fitted with stainless steel forged ring and forged lid, chamber & jacket are fitted with two safety valve of stainless steel, pressure gauge, water outlet and inlet ball valve and vacuum breaker Air inlet valve, stainless steel steam condenser, tube with stainless steel eject valve.
Steam Generator :
- The steam generator is made out of stainless steel heavy gauge fitted with pressure gauge and water draining valve.
Outer Cover :
- The steam generates from the jacket and gets condensed by the help of the eject valve which goes through condensing tube and the dry steam gets into the chamber to penetrate into the packs contained in the chamber.
Operating Temperature, Pressure & Voltage :
- Sterilizing Temp.: 121°C & 134°C.
- Sterilizing Pressure: 1.2 to 2.2 kg/ cm2 (15 PSI to 30 PSI)
- Power supply 230V/ 440v, 3Ph, 50Hz.
Other Features :
- Chamber / Jacket of S.S. 316/304
- Door of S.S. 304/316
- Three sensor, one sensor is main controlling drain line and two sensor are scanning of different types of chamber area.
- Digital Temperature controller.
- Top loading radial locking door.
- Automatic low water level cut off systems.
- High & low temperature alarm.
- Built thermal printer facility.
- Fully automatic HMI / PLC controller with printer.
Optional Spare Accessories :
- Pressure gauge / Compound gauge
- Water level glass tube.
- Temperature Gauge.
- Non return valve.
- Moisture trap.
- Joint less Gasket : Neoprene / silicon food fade rubber.
- Heating elements (Flange Type) Rating 6.0 kw, 9.0kw, 12kw.
| Available in Following Capacities | |||||
|---|---|---|---|---|---|
| Dia (mm) | Depth (mm) | Capacity (Ltr.) | Elect. Load (kw) | Voltage | Model No. |
| 300 | 500 | 48 | 3 | 35 | 58-1365 |
| 350 | 500 | 50 | 3 | 50 | 58-1367 |
| 400 | 600 | 78 | 6 | 75 | 58-1369 |
| 450 | 600 | 98 | 6 | 95 | 58-1371 |
| 500 | 700 | 137 | 6 | 168 | 58-1373 |
| 550 | 750 | 178 | 9 | 180 | 58-1375 |
